Top Entry Ball Valve

Product Description

This product is a new type of top entry combination ball valve, the seat can be installed and move around the body. Through the thread, the outer edge of the seat is attached to the retainer ring. There is a spring in the support cover, a spring in the valve body, and a spring that can be compressed by the retainer ring. The fabrication holes are located on the outer edges of the seat and retainer rings. The new product features a total body design that automatically compensates for small likelihood of leakage, safety in use, vibration resistance, and double sealing. The ball is mounted from the top, so that repairs can be completed without removing the pipe, which is very convenient.

Features & Benefits
● Top-Mounted Design: Facilitates easy maintenance directly in the pipeline, reducing downtime and costs, and increases durability.
● Advanced Seal Design: Features a floating seat for reliable sealing at all pressures and includes fire-safe components.
● Emergency and Regular Lubrication: Allows for emergency sealing and regular lubrication through a built-in grease valve to ensure
smooth operation.
● Extended Stem: Offers customizable stem lengths for ease of maintenance, especially in underground installations.
● Anti-Static Safety: Built to prevent static buildup, meeting API6D and ISO17292 standards.
● Dual Block and Bleed: Capable of isolating both upstream and downstream media, with automatic pressure relief for safety.
● Low Torque Operation: Designed with a fixed ball and sliding bearings to reduce friction and ease operation.
